A production line for crushing and sorting magnetite with a capacity of 450 tons per hour.
In the context of the continuous development of environmentally friendly mining and efficient resource utilization, mining companies are constantly seeking effective and environmentally safe production solutions. The magnetite crushing and screening project with a capacity of 450 tons per hour, utilizing advanced equipment from SBM Group, demonstrates a promising future for environmentally friendly mining.
Other examples of magnetite crushing projects
Project Overview
Project capacity: 450 tons/hour (crushing and screening system)
Raw material: Magnetite iron ore
Maximum size of raw material: 760 mm
Finished product size:<10 mm
Equipment configuration
C6X125 Jaw Crusher
HST260S Single-cylinder Hydraulic Cone Crusher
HPT400 Multi-cylinder Hydraulic Cone Crusher
S5X3075 Vibrating Screen
Advanced three-stage crushing scheme
The project uses a three-stage crushing scheme with preliminary screening of medium and fine crushed products in accordance with the characteristics of the ore's particle size distribution. This increases the productivity of the system with the same configuration, reduces the size of product particles, meets the requirements of multi-stage crushing and finer grinding, thereby reducing grinding costs. The resulting sand from iron ore tailings can be used in the production of non-fired bricks and cement, ensuring the comprehensive utilization of waste. The crushing and screening system will provide the grinding and beneficiation plant with high-quality fine-grained powder (fraction output -5 mm > 60%), effectively reducing operating costs for grinding and beneficiation and enriching magnetite minerals.
Advantages and applications of SBM equipment
SBM group equipment plays a vital role in the project:
C6X Jaw Crusher: Suitable for primary crushing of large stones, characterized by high efficiency and stability.
HST Single-Cylinder Hydraulic Cone Crusher: Used in the medium and fine crushing stages, providing fine crushing results and adapting to various production needs in terms of particle size.
HPT Multi-Cylinder Cone Crusher: Demonstrates outstanding results in artificial sand production, providing excellent sand particle shape and uniform particle size, meeting high construction standards.
S5X Vibrating Screen: High screening efficiency ensures uniform product particle size. These devices, thanks to their intelligent control system, provide real-time monitoring and efficient production, fully utilizing tailings waste and comprehensively contributing to the development of environmentally friendly mining production. Success Stories
2.5 Million Tons Per Year Magnetite Crushing and Beneficiation Project in Baotou
The 2.5 million tons per year magnetite crushing production line in Baotou is one of three production lines developed in cooperation between SBM and its clients. The project uses an inclined shaft mining method and equipment such as the PEW jaw crusher, C6X jaw crusher, HST single-cylinder hydraulic cone crusher, and HPT multi-cylinder hydraulic cone crusher manufactured by SBM Group. Since commissioning, the equipment has been operating stably. SBM's technical and after-sales service engineers have repeatedly visited the site to address any problems encountered during production.
3.5 Million Tons Per Year Magnetite Crushing and Beneficiation Project in Bayannur
The 3.5 million tons per year magnetite crushing production line located in Bayannur uses equipment such as the C6X jaw crusher, HST single-cylinder hydraulic cone crusher, HPT multi-cylinder cone crusher, and S5X vibrating screen manufactured by SBM Group. After the client invested 62 million yuan in comprehensive technical upgrading and expansion in 2021, SBM engineers conducted systematic training for the operating and maintenance personnel.After the successful commissioning and maintenance of the equipment, the mining site officially transitioned to full-scale production.
Conclusion
Thanks to the application of advanced equipment from SBM Group, numerous magnetite crushing and beneficiation projects have achieved efficient and environmentally friendly production. SBM Group will continue to provide high-quality equipment and solutions to mining companies, contributing to the efficient and sustainable development of the industry.
