Construction Plan and Equipment Selection for an 800-ton-per-hour Granite Sand and Gravel Aggregate Production Line in Sichuan

To meet local demand for sand and gravel aggregates, Sichuan Province is constructing a production line with a capacity of 800 tons per hour. The equipment selection is as follows:

Project Overview:

Capacity: 800 tons/hour

Material: Granite

Finished Product Particle Size: 0-5-10-20-30mm

Equipment Configuration: F5X Feeder + C6X Jaw Crusher + HST Cone Crusher + VSI6X Impact Crusher + S5X Vibrating Screen

Finished Product Application: Commercial concrete, light rail construction, and other sand and gravel materials

Sand and Gravel Aggregate Production Line Construction Plan Consultation

Main Equipment Introduction:

1. F5X Feeder: The feeder is used to continuously and evenly feed raw materials into the crusher. F5X may be a specific model or series of feeders with specific performance and specifications.

2. C6X Jaw Crusher: A jaw crusher uses two jaw plates to crush raw materials into smaller particles. C6X may indicate the model or specification of this jaw crusher.

3. HST Cone Crusher: A cone crusher is a type of crusher that uses the friction between a rotating cone and a fixed wall to crush raw materials. HST may refer to this type or series of cone crushers.

4. VSI6X Impact Crusher: An impact crusher is a type of impact crusher that uses high-speed rotating hammers or blades to crush raw materials. VSI6X may indicate the model or specification of this impact crusher.

5. S5X Vibrating Screen: A vibrating screen is a device used to screen crushed raw materials, separating them into different grades according to their particle size and shape. S5X may indicate the model or specification of this vibrating screen.
