How to configure a stone crushing line with a capacity of 300-400 tons per hour, and what is the approximate cost of such a line?
I. Configuration Plan for a Limestone Crushing Line with a Capacity of 300-400 t/h
Finished product sizes: 0-5, 5-9.5, 9.5-16.5, 16.5-26.5 mm
Equipment configuration: F5X1345 vibrating feeder, PEW860 European-type jaw crusher, 2 PFW1315Ⅲ impact crushers, VSI5X1145 sand making machine, S5X2760-2 vibrating screen, S5X2460-3 vibrating screen
Note: The feeder can pre-screen the material during feeding, acting as a soil removal device.
Learn more about sand and aggregate production line configuration plans by clicking for information.
The F5X1345 vibrating feeder, thanks to its high efficiency and stable operation, ensures uniform and continuous feeding of materials to the production line. The PEW860 European-type jaw crusher, with its excellent crushing performance and durability, effectively processes materials of varying hardness. Two PFW1315Ⅲ impact crushers, characterized by high efficiency and low wear, provide high-quality crushing. The VSI5X1145 sand making machine is focused on the production of fine sand, ensuring good sand particle shape and excellent quality. The S5X2760-2 and S5X2460-3 vibrating screens, as sorting equipment, allow for precise separation of materials of different sizes, ensuring product quality. The entire production line has a rational configuration, and the equipment works in synergy, ensuring an efficient and environmentally friendly material processing process.
The process flow diagram is as follows:
II. Configuration plan for a stone crushing and sand production line from granite with a capacity of 350-400 t/h
Finished product sizes: 0-5-10-20-31.5 mm
Equipment configuration: PEW jaw crusher, 2 HPT300 multi-cylinder hydraulic cone crushers, 2 S5X2460-2 vibrating screens, etc.
The process flow diagram is as follows:
How much does a crushed stone production line cost?
The price of a production line varies depending on the client's needs; there is no fixed standard. Different capacity requirements determine the choice of crusher and sand making machine models, which in turn affects the overall price, which can range from hundreds of thousands to millions of yuan. The manufacturer also affects the price; equipment from large manufacturers is often more expensive, but usually has a better quality guarantee. When choosing a production line, customers need to consider their own needs, budget, and equipment quality.
