Equipment for the production of sand and gravel with a capacity of 300 tons per hour.

What equipment for sand and aggregate production can provide a capacity of 300 tons per hour? How to configure a sand and aggregate production line with a capacity of 300 tons per hour? Below are several configuration options for your reference:

Learn more about sand and aggregate production equipment, click to send an inquiry.

1. Configuration of a 300 t/h limestone sand production line (I)

This configuration includes several sets of feeders, crushers, and screening and washing equipment. Two GZD-11004200 feeders ensure stable material feeding; two PE-600900 jaw crushers are used for primary crushing; two PF-1214 impact crushers perform secondary crushing; two VSI-8518 vertical shaft impact crushers provide efficient fine crushing; two 2YK1545 and two 4YK1548 vibrating screens are responsible for sorting materials into different particle sizes; three XSD3016 sand washing machines ensure the quality of the sand. The complete set of equipment is well-configured to meet the needs of efficient and precise crushing, screening, and sand washing.

The technological process flow chart is as follows:

2. Configuration of a limestone sand production line with a capacity of 300-400 t/h (II)

Equipment configuration: F5X1345 vibrating feeder, PEW860 European-type jaw crusher, 2 PFW1315Ⅲ impact crushers, VSI5X1145, S5X2760-2 vibrating screen, S5X2460-3 vibrating screen
